Spiral Submerged Arc Welded Pipe SSAW
The spiral submerged arc welded pipe is made of hot-rolled steel strip through constant temperature spiral forming and automatic submerged arc welding. The manufacturing process is to roll the steel strip, make the rolling direction at a certain angle to the center direction of the tube, and then form and weld, so the weld is spiral.
Contact me via WhatsApp
Submit

Spiral Submerged Arc Welded Pipe SSAW Description

Submerged  arc welding is an important welding method. Its inherent advantages  include stable welding quality, high welding productivity, no arc light  and little smoke, making it an ideal choice  in  the production of important steel structures such as pressure vessels,  pipe section manufacturing, box beam and column manufacturing. The  strength of SSAW spiral welded pipes is generally higher than that of  straight seam welded pipes. Welded pipes with larger diameters can be  produced from narrower billets, and welded pipes with different  diameters can also be produced from billets of the same width.


Product Parameters

Product Name

Spiral Submerged Arc Welded Pipe SSAW

Standard

EN/DIN/JIS/ASTM/BS/ASME/AISI etc.

Outer Diameter

219.1mm-3580mm

Wall Thickness

3.2mm-25.4mm

Length

5.8 meters-12.5 meters, Support customization

Manufacturing Type

Spiral Welding

Product Material

Standard

Material

GB/T3091

Q235B, Q345A, Q345B

GB/T9711-2011

L210, L245, L290, L320, L360, L390, L415, L450, L485

API 5L PSL1

Gr.A, Gr.B, X42, X46, X52, X56, X60, X65, X70, X80

API 5L PSL2

Gr.B, X42, X46, X52, X56, X60, X65, X70, X80

EN10217

P235TR1, P235TR2, P265TR1, P265TR2

ASTM A252

A252 Gr.2 , A252 Gr.3



Chemical Composition & Mechanical Properties

Standard

Grade

Chemical Composition (%)

Mechanical Properties (min)

C

Si

Mn

P

S

Tensile Strength (Mpa)

Yield Strength (Mpa)

API 5CT

H40

-

-

-

-

0.030

417

417

J55

-

-

-

-

0.030

517

517

K55

-

-

-

-

0.300

655

655

API 5L PSL 1

A

0.22

-

0.90

0.030

0.030

335

335

B

0.26

-

1.20

0.030

0.030

415

415

X42

0.26

-

1.30

0.030

0.030

415

415

X46

0.26

-

1.40

0.030

0.030

435

435

X52

0.26

-

1.40

0.030

0.030

460

460

X56

0.26

-

1.40

0.030

0.030

490

490

X60

0.26

-

1.40

0.030

0.030

520

520

X65

0.26

-

1.45

0.030

0.030

535

535

X70

0.26

-

1.65

0.030

0.030

570

570

API 5L PSL 2

B

0.22

0.45

1.20

0.025

0.015

415

415

X42

0.22

0.45

1.30

0.025

0.015

415

415

X46

0.22

0.45

1.40

0.025

0.015

435

435

X52

0.22

0.45

1.40

0.025

0.015

460

460

X56

0.22

0.45

1.40

0.025

0.015

490

490

X60

0.12

0.45

1.60

0.025

0.015

520

520

X65

0.12

0.45

1.60

0.025

0.015

535

535

X70

0.12

0.45

1.70

0.025

0.015

570

570

X80

0.12

0.45

1.85

0.025

0.015

625

625

ASTM A53

A

0.25

0.10

0.95

0.050

0.045

330

330

B

0.30

0.10

1.20

0.050

0.045

415

415

ASTM A252

1

-

-

-

0.050

-

345

345

2

-

-

-

0.050

-

414

414

3

-

-

-

0.050

-

455

455

EN 10217-1

P195TR1

0.13

0.35

0.70

0.025

0.020

320

320

P195TR2

0.13

0.35

0.70

0.025

0.020

320

320

P235TR1

0.16

0.35

1.20

0.025

0.020

360

360

P235TR2

0.16

0.35

1.20

0.025

0.020

360

360

P265TR1

0.20

0.40

1.40

0.025

0.020

410

410

P265TR2

0.20

0.40

1.40

0.025

0.020

410

410

EN 10217-2

P195GH

0.13

0.35

0.70

0.025

0.020

320

320

P235GH

0.16

0.35

1.20

0.025

0.020

360

360

P265GH

0.20

0.40

1.40

0.025

0.020

410

410

EN 10217-5

P235GH

0.16

0.35

1.20

0.025

0.020

360

360

P265GH

0.20

0.40

1.40

0.025

0.020

410

410

EN 10219-1

S235JRH

0.17

-

1.40

0.040

0.040

360

360

S275JOH

0.20

-

1.50

0.035

0.035

410

410

S275J2H

0.20

-

1.50

0.030

0.030

410

410

S355JOH

0.22

0.55

1.60

0.035

0.035

470

470

S355J2H

0.22

0.55

1.60

0.030

0.030

470

470

S355K2H

0.22

0.55

1.60

0.030

0.030

470

470



Scope of Application

Petroleum and natural gas industry,  chemical industry, power industry, flammable liquid and incombustible  liquid pipeline and building structure, water supply and drainage  engineering, urban construction.

   Product Show

   Why Choose Us

1.7x24 hours online response

7x24 hours online response

Only to give you the best service

2.Punctual delivery

(1) We provide competitive price products on the basis of quality assurance and arrange delivery on time.

(2) We can process different finished products according to your requirements

(3) High production capacity will shorten your waiting time

(4) Accept buyer's specifications

(5) Experienced R&D department

   Certificates


    Our Factory

   Packaging&Shipping

   FAQ

Q: Are you a trading company or a manufacturer?

A: We are a professional manufacturer and offer a wide range of steel products.

Q: Do you provide samples?

A: Yes, we will provide samples for free, and the express shipping cost will be borne by customers.

Q: Can you customize the products according to our requirements?

A: Yes, just tell us your requirements, we can provide you with customized solutions, such as material, hardness, thickness, width and so on.

Q: Can I visit your factory?

A: Of course you can, we welcome customers from all over the world to visit our factory.

Q: Are the products quality inspected before shipment?

A: Of course, all our products undergo strict quality inspection before packing, and unqualified products will be destroyed. We absolutely accept third party inspection.
